Edge Series Fixed Frame Screen - R7
The R7 model retains the slim frame design of the Xianying series, offering users a choice between 12mm and 15mm frames. Its innovative embedded buckle installation structure simplifies the installation process. Compared to other screens of the same size, it reduces packaging length by 45%, volume by 43%, and weight by 30%, making transportation more convenient.
• Frame options：12mm / 15mm
• DY1C / DY1D / DY1D-UW Maximum size:120"(16:9)
• DY3 / DY5 Maximum size:120"(16:9)
• DY3-T Maximum size:100"(16:9)
• 150 inches Maximum size of Standard throw screen
-
UHD130
130°
Viewing
Angle1.3
Gain
-
WW5
160°
Viewing
Angle1.0
Gain
-
Black Grid (DY3)
140°
Viewing
Angle0.5
Gain
-
DY4
140°
Viewing
Angle0.6
Gain
-
Black Grid(DY5)
140°
Viewing
Angle0.6
Gain
-
DY1C
>56°
Viewing
Angle1.6
Gain
-
Black Grid(DY3T)
140°
Viewing
Angle0.5
Gain
-
DY1D
50°
Viewing
Angle1.3
Gain
-
DY7
140°
Viewing
Angle1.2
Gain
-
DY2C-P
>56°
Viewing
Angle1.5
Gain
-
Edge-Lite Series - DY1D-UW
135°
Viewing
Angle1.0
Gain
- 12mm
- 15mm
- 16:9
- 16:10
- 80"
- 84"
- 92"
- 96"
- 100"
- 106"
- 110"
- 112"
- 120"
- 133"
- 145"
- 150"
Parameter
- Diagonal Measurement
-
Viewing Area
（W×H）mm -
Product Height
（A）mm -
Black Drop
（B3）mm -
Lower Border
（B2）mm -
Left/Right
（B1）mm -
Product Length
（L） -
Endcap Height
（Hc）mm -
Endcap Width
（Wc）
Edge Series(R7) Fixed Frame Screen User Manual (Accoustic Transparent Fabric) (PDF)
